Solar Tracking Actuator Systems or Sun Panel Trackers Linear Actuators DC 12V 24V 36V Motor.
JAC6 SOLAR TRACKING ACTUATORS
JAC6 SPECIFICATIONS
* Model: JAC6
* Input Voltage: DC 36V (DC 24V /12V)
* Rated Load: 1500N
* Max. Static Load: 6000N
* Dynamic Load: 2850N
* Stroke Length: 8″ (200MM), 12″ (300MM), 18″ (450MM), 24″ (600MM), Custom Made
* Load Current: ≤1.8A
* Screw Drive Type: ACME Screw
* Travel Speed: 6 MM/Sec
* Duty Cycle: 20%
* Working Temperature: -26 Deg. C~65 Deg. C (-15 Deg. F~150 Deg. F)
* Stroke Length is Adjustable by Limit Switches
* Sensor Type: Reed Switch Sensor
* Bronze Traveling Nut & ACME Screw Set Qty: 1PC
JAC9 SOLAR TRACKING ACTUATORS
JAC9 SPECIFICATIONS
* Model: JAC9
* Input Voltage: DC 36V (DC 24V /12V)
* Rated Load: 2500N
* Max. Static Load: 9000N
* Dynamic Load: 5500N
* Stroke Length: 18″ (450MM), 24″ (600MM), 36″ (900MM). Custom Made is Acceptable.
* Load Current: ≤2.5A
* Screw Drive Type: ACME Screw
* Travel Speed: 5 MM/Sec
* Duty Cycle: 20%
* Working Temperature: -26 Deg. C~65 Deg. C (-15 Deg. F~150 Deg. F)
* Stroke Length is Adjustable by Limit Switches
* Sensor Type: Reed Switch Sensor / POT
* Bronze Traveling Nut & ACME Screw Set Qty: 1PC
JAC15 SOLAR TRACKING ACTUATORS
JAC15 SPECIFICATIONS
* Model: JAC15
* Input Voltage: DC 36V (DC 24V)
* Rated Load: 4500N
* Max. Static Load: 15000N
* Dynamic Load: 6500N
* Stroke Length: 18″ (450MM), 24″ (600MM), 36″ (900MM). Custom Made is Acceptable.
* Load Current: ≤3.5A
* Screw Drive Type: ACME Screw
* Travel Speed: 2.8 MM/Sec
* Duty Cycle: 20%
* Working Temperature: -26 Deg. C~65 Deg. C (-15 Deg. F~150 Deg. F)
* Stroke Length is Adjustable by Limit Switches
* Sensor Type: Reed Switch Sensor
* Bronze Traveling Nut & ACME Screw Set Qty: 1PC
* Sensor Type: Reed Switch Sensor / POT
JAC20 SOLAR TRACKING ACTUATORS
JAC20 SPECIFICATIONS
* Model: JAC20
* Input Voltage: DC 36V (DC 24V)
* Rated Load: 6000N
* Max. Static Load: 20000N
* Dynamic Load: 8100N
* Stroke Length: 18″ (450MM), 24″ (600MM), 36″ (900MM). Custom Made is Acceptable.
* Load Current: ≤4.0A
* Screw Drive Type: ACME Screw
* Travel Speed: 3.2 MM/Sec
* Duty Cycle: 20%
* Working Temperature: -26 Deg. C~65 Deg. C (-15 Deg. F~150 Deg. F)
* Stroke Length is Adjustable by Limit Switches
* Sensor Type: Reed Switch Sensor / POT
* Bronze Traveling Nut & ACME Screw Set Qty: 1PC
